PRODUCT INFO
The Ergo Work Positioner is designed to enable the operator to move the work to positions that are suitable for their needs. By allowing full flexibility to easily adjust to any comfortable work height, it’s an economical solution to create a safe, comfortable workplace while reducing the potential for expensive work injuries.
- Makes parts easily reachable
- Prevents back strain
- Increases productivity.
OPTIONS & Resources
- Different straddle leg sizes
- Different fork width lengths and heights
- D/C battery powered with hand held pendant
- Slip-on platforms
TECHNICAL SPECIFICATIONS
CAPACITY:
1,000/2,000/3,000 lbs
LIFT HEIGHT:
36″, 48″, 60″
LOWERED HEIGHT:
3-1/4″
SAFETY:
Velocity fuse on each cylinder
Floor lock
POWER SUPPLIES:
D/C 12 volt battery with joy stick activation and a built in 12 volt charger (standard)
A/C 110 volt – Hand held pendant (optional)
Straddle Ergo Work Positioner
| SEWP MODEL NO. | CAPACITY (Lbs.) | RAISED HEIGHT (In.) | LOW'D FORK HEIGHT (In.) | FORK WIDTH (In.) | FORK LENGTH (In.) | STRADDLE I.D. (In.) | SHIP WEIGHT (Lbs) |
|---|---|---|---|---|---|---|---|
| SEWP36-10 | 1000 | 36 | 3-1/4 | 26-1/2 | 42 | 50 | 600 |
| SEWP36-20 | 2000 | 36 | 3-1/4 | 26-1/2 | 42 | 50 | 650 |
| SEWP36-30 | 3000 | 36 | 3-1/4 | 26-1/2 | 42 | 50 | 675 |
| SEWP48-10 | 1000 | 48 | 3-1/4 | 26-1/2 | 42 | 50 | 625 |
| SEWP48-20 | 2000 | 48 | 3-1/4 | 26-1/2 | 42 | 50 | 675 |
| SEWP48-30 | 3000 | 48 | 3-1/4 | 26-1/2 | 42 | 50 | 700 |
| SEWP60-10 | 1000 | 60 | 3-1/4 | 26-1/2 | 42 | 50 | 650 |
| SEWP60-20 | 2000 | 60 | 3-1/4 | 26-1/2 | 42 | 50 | 675 |
| SEWP60-30 | 3000 | 60 | 3-1/4 | 26-1/2 | 42 | 50 | 725 |
Ergo Work Positioner
| EWP MODEL NO. | CAPACITY (Lbs.) | RAISED HEIGHT (In.) | LOW'D FORK HEIGHT (In.) | FORK WIDTH (In.) | FORK LENGTH (In.) | SHIP WEIGHT (Lbs) |
|---|---|---|---|---|---|---|
| EWP36-10 | 1000 | 36 | 3-1/4 | 26-1/2 | 42 | 600 |
| EWP36-20 | 2000 | 36 | 3-1/4 | 26-1/2 | 42 | 650 |
| EWP36-30 | 3000 | 36 | 3-1/4 | 26-1/2 | 42 | 675 |
| EWP48-10 | 1000 | 48 | 3-1/4 | 26-1/2 | 42 | 625 |
| EWP48-20 | 2000 | 48 | 3-1/4 | 26-1/2 | 42 | 675 |
| EWP48-30 | 3000 | 48 | 3-1/4 | 26-1/2 | 42 | 700 |
| EWP60-10 | 1000 | 60 | 3-1/4 | 26-1/2 | 42 | 650 |
| EWP60-20 | 2000 | 60 | 3-1/4 | 26-1/2 | 42 | 675 |
| EWP60-30 | 3000 | 60 | 3-1/4 | 26-1/2 | 42 | 725 |
